Multi Functional Led Digital Screen Advertising OEM / ODM Available

Name: Multi Functional Led Digital Screen Advertising OEM ODM Available
Brand: Shenzhen LED World
Price: 1 USD

China Multi Functional Led Digital Screen Advertising OEM / ODM Available wholesale

Brand Name : Shenzhen LED World

Model Number : LW-RO 6.25

Certification : CE,RoHS,FCC

Place of Origin : China

MOQ : 1 square meter

Price : Negotiation

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 3,000 square meters per month

Delivery Time : 12-20 working days after received your payment

Packaging Details : Carton/Plywood case etc.

Maintenance : Rear

Driver IC : MBI5124

IP Rating : IP65(front) /IP54 (back)

Brightness(CD/M2) : ≥5500

Refresh Rate : ≥1920Hz

Pitch : P6.25 / P4.81 / P3.91 / P5.68

Module Size(H*W/mm) : 250*250 mm

Encapsulation : SMD3535

Contact Now

6.25mm pixel pitch Advertising LED Displays 16:9 ratio 500x500 die-caste cabinet

Features:

Can be used both outdoors and indoors;
High definition,25600 Pixels/sqm,can show extremely clear and vivid video,images and texts,looking very high end;
Cabinet size:500mmW*500mmH, thickness around 60mm, only7.8Kg;It can be P3.91, P4.81, P5.68 and P6.25;
Module size of 250x250mm, can be assembled with 500x500mm and 500x1000mm;
The resolution is 30976 pixels per square meter so definition is high enough for showing video, images and it's clear enough when viewed in short distance;
Multifunctional cabinet, just change the module to upgrade the product with low cost;
Can be flat screen and curved screen, one screen, multiple use, you can shape anything you want;
Angle adjustment
Using angle adjustment structure, panels could be assembled into different shape like convex and concave, the angle range is ±15° .
The same cabinet can be compatible with different pitches:P4.8/P3.91/P6.25Some pictures showing as belo for your reference:Some pictures showing below for your reference;
P4.8 and P6.25 can be used both outdoors and indoors;

Application:
Our full color LED display are widely used in chain shop,Building facilities,Outdoor Signage and advertisement,hospitals,live show,Offices,travel agency,airport,high-rise building roof,theme parks,financial industry, entertainment venues,fitness hall,stores office building,Football fields,studio,Entertainment centers,theaters,high-speed rail station,outside parking lots and so on.

Parameter:

Pitch	Outdoor
Pitch	P6.25mm
Encapsulation	SMD3535
Pixel Configuration	1R1G1B
Driver Method	1/10
Module Size(H*W/mm)	250*250/
Module Size(H*W/mm)	250*500
Module Resolution(H*W/dots)	40*40/
Module Resolution(H*W/dots)	40*80
Pixel Density(dots/M²)	25600
Average Power Consumption	260
(Watt/M²)	260
Max. Power Consumption	750
(Watt/M²)	750
Brightness(CD/M²)	≥5500
Cabinets Size(WHT/mm)	500*500/
Cabinets Size(WHT/mm)	1000*500
Unit Cabinet Weight(kg)	7.8kg/12kg
Driver IC	MBI5124
IP Rating	IP65(front) /IP54 (back)
Installation Method	Fixed / Hung up
Cabinets material	Die-cast aluminum
View Angle	160⁰(H)/ 140⁰(V)
Refresh Rate	≥1920Hz
Frame Frequency	≥60Hz
Voltage Input	AC110V/220V±15% 40~65HZ
Operating Temperature	-20ºC~60ºC ,storage for :-30oC~+90oC
Maintenance	Rear
System Working Environment Humidity	10%-90%RH
Life Span(Hours)	≥55,000Hours
Color Temperature	5600K±500
Power Supply	G-energy with CE/UL proof
Control system support	Linsn/ Novastar
Compliant standard	CE, CCC, UL
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Our service:

We promise you more than just two years warranty service;
User's manual, instruction video, professional CAD installation drawing, and other needed engineering drawings will be provided;
Under normal use and storage, Our Company will be responsible for the equipments;
Service principles: Response in time, solve problems as soon as possible and ensure the use;

Hanging beam:
